Characteristics:
This model is one of the most favorite on the international market. It was scientifically and specially designed, is easy to install and operate. The important point is solar water heater can feed water automatically and ensure the outlet water as stable temperature, solar geyser will always provide you hot water.
Specification:
Inner tank: SUS 304-2B/0.31mm/0.41mm/0.5mm
Outer tank: Galvanized steel/Stainless steel/0.31mm/0.41mm
Insulation: High density polyurethane foam 50mm/55mm/60mm
Vacuum tube: Ø58*1800mm, AL-N-AL coating
Bracket: Galvanized steel 1.5mm, 0-50 degree/ stainless steel 1.0mm,0-50 degree/ Aluminum alloy 0.9mm
Accessories: UV stablilized high temperature silicon
Capacity: 150L 180L 200L 250L 300L
| Type | Area(M 2 ) | Vacuum tube | Volume(L) | GrossWeight (KG) | 20GP/40GP/40HQ Loading Qty(sets) | ||
| Dim(mm) | Length(mm) | Qty(pcs) | |||||
| DIYI-NP01-8 | 0.978 | 58 | 1800 | 8 | 80 | 32 | 82/170/200 |
| DIYI-NP01-10 | 1.332 | 58 | 1800 | 10 | 100 | 40 | 74/151/177 |
| DIYI-NP01-12 | 1.578 | 58 | 1800 | 12 | 120 | 51 | 61/127/150 |
| DIYI-NP01-15 | 1.979 | 58 | 1800 | 15 | 150 | 58 | 53/109/130 |
| DIYI-NP01-18 | 2.382 | 58 | 1800 | 18 | 180 | 65 | 48/93/112 |
| DIYI-NP01-20 | 2.651 | 58 | 1800 | 20 | 200 | 70 | 40/82/98 |
| DIYI-NP01-25 | 3.189 | 58 | 1800 | 25 | 250 | 80 | 30/64/75 |
| DIYI-NP01-30 | 3.995 | 58 | 1800 | 30 | 300 | 100 | 28/52/67 |
